Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 253

Configure Switch Features Chapter 7

Configure IGMP Snooping via Device Manager

From the Configure menu, choose IGMP Snooping:

• To enable IGMP Snooping for all VLAN IDs, check Enable next to

IGMP Snooping.

• To enable IGMP Querier for all VLAN IDs, check Enable next to

IGMP Querier.

• To enable or disable IGMP snooping on a VLAN, select the VLAN and

check or clear the Enable IGMP Snooping checkbox.
