Install Stratix 8000 and 8300 Switches Chapter 6
Specifications
For additional specifications and certifications, see the Stratix Ethernet Device
Specifications Technical Data, publication
1783-TD001.
ATTENTION: To comply with the CE Low Voltage Directive (LVD), all connections to this equipment must be powered from a
source compliant with safety extra low voltage (SELV) or protected extra low voltage (PELV).
To comply with UL restrictions, all connections to this equipment must be powered from a source compliant with Class 2 or Limited
Voltage/Current.
Table 28 - Stratix 8000 and 8300 Switches
Attribute 1783-MS06T, 1783-MS10T, 1783-RMS06T, 1783-RMS10T 1783-MX08T 1783-MX08F 1783-MX04S 1783-MX08S
Wire size, power connectors 0.5…0.8 mm
2
(18…20 AWG) twisted-pair copper wire suitable for
86 °F (30 °C) above surrounding ambient temperature outside of the
enclosure
NA
Screw torque, ground terminals 0.96 N•m (8.5 lb•in)
Screw torque, relay terminals 0.23 N•m (2.0 lb•in)
Screw torque, power terminals
Alarm relay ratings 30V DC, 1.0 A max
Power supply, user supplied 18…60V DC, 2.0 A max NA
Power consumption, expansion
modules
NA 3.3V DC, 1.7 A
max
3.3V DC, 3.6A
max
3.3V DC, 2.5 A
max
3.3V DC, 4.0 A
max
Table 29 - Stratix 8000 and 8300 Power over Ethernet Expansion Modules
Attribute 1783-MX04E 1783-MX04T04E
Wire size, power connectors 0.5…0.8 mm
2
(18…20 AWG) twisted-pair copper wire suitable for 30 °C (86 °F) above surrounding ambient temperature outside the
enclosure
Screw torque, ground terminals 0.96 N•m (8.5 lb•in)
Screw torque, power terminals 0.23 N•m (2.0 lb•in)
DC input voltage, PoE 48/54V DC
DC input current, PoE 2.5 A 2.5 A
Power consumption, module 7.3 W 7.9 W
Backplane power, module 3.3V DC @ 0.94 A 3.3V DC @ 1.08 A
