Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 387
Monitor the Switch Chapter 8
Port Utilization
You can choose which types of network traffic to display and in what format:
• Types of traffic—By default, all traffic is displayed for all interfaces.
Click the links above the display area to display all traffic, errors,
received traffic, or transmitted traffic.
• Formats—Click the buttons below the display area to view the data in
Chart Mode or Grid Mode.
• Chart details—When displaying a chart, position your mouse pointer
over a bar or a point on the chart to view the data.
As you monitor the usage on the ports, note whether the percentage is what
you expect during that given time of network activity. If usage is high when you
expect it to be low, a problem can exist. Bandwidth allocation can also be based
on whether the connection is operating in Half-duplex or Full-duplex mode.
Reasons for errors that are received on or sent from the switch ports include the
following:
• Bad cable connection
• Defective ports
• Software problems
• Driver problems
Data is collected at each 60-second system refresh.
See
Trends on page 394 for a graph to view per-port patterns over incremental
instances in time (by 60 seconds, 1 hour, 1 day, or 1 week).
See
Port Statistics on page 395 for details on the specific port errors that are
detected on each port.
