Allen-Bradley Stratix 5400 User Manual

492 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix B Port Assignments for CIP Data
ArmorStratix 5700
Port Assignments
19 Fa1/19 Gi1/1
20 Fa1/20 Gi1/2
27 SVI1 SVI1 SVI1
Table 163 - 18- and 20-port Switches (continued)
Bit 1783-BMS12T4E2CGL, 1783-BMS12T4E2CGP,
1783-BMS12T4E2CGNK
1783-BMS20CL, 1783-BMS20CA 1783-BMS20CGL, 1783-BMS20CGN,
1783-BMS20CGP, 1783-BMS20CGPK
Bit 1783-ZMS8TA 1783-ZMS4T4E2TGP,
1783-ZMS4T4E2TGN
1783-ZMS16TA 1783-ZMS8T8E2TGP,
1783-ZMS8T8E2TGN
1783-ZMS24TA
0 Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports
1 Fa1/1 Fa/1 Fa1/1 Fa1/1 Fa1/1
2 Fa1/2 Fa1/2 Fa1/2 Fa1/2 Fa1/2
3 Fa1/3 Fa1/3 Fa1/3 Fa1/3 Fa1/3
4 Fa1/4 Fa1/4 Fa1/4 Fa1/4 Fa1/4
5 Fa1/5 Fa1/5 Fa1/5 Fa1/5 Fa1/5
6 Fa1/6 Fa1/6 Fa1/6 Fa1/6 Fa1/6
7 Fa1/7 Fa1/7 Fa1/7 Fa1/7 Fa1/7
8 Fa1/8 Fa1/8 Fa1/8 Fa1/8 Fa1/8
9 Gi1/1 Fa1/9 Fa1/9 Fa1/9
10 Gi1/2 Fa1/10 Fa1/10 Fa1/10
11 Fa1/11 Fa1/11 Fa1/11
12 Fa1/12 Fa1/12 Fa1/12
13 Fa1/13 Fa1/13 Fa1/13
14 Fa1/14 Fa1/14 Fa1/14
15 Fa1/15 Fa1/15 Fa1/15
16 Fa1/16 Fa1/16 Fa1/16
17 Gi1/1 Fa1/17
18 Gi1/2 Fa1/18
19 Fa1/19
20 Fa1/20
21 Fa1/21
22 Fa1/22
23 Fa1/23
24 Fa1/24
27 SVI1 SVI1 SVI1 SVI1 SVI1
