Appendix B Port Assignments for CIP Data
Stratix 5400
Port Assignments
Table 160 - 8- and 12-port Switches
Bit 1783-HMS4C4CGN 1783-HMS8T4CGN 1783-HMS8S4CGN 1783-HMS4T4E4CGN 1783-HMS8TG4CGN
1783-HMS8TG4CGR
1783-HMS8SG4CGN
1783-HMS8SG4CGR
1783-HMS4EG8CGN
1783-HMS4EG8CGR
0 Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports Any/All ports
1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1 Gi1/1
2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2 Gi1/2
3 Gi1/3 Gi1/3 Gi1/3 Gi1/3 Gi1/3 Gi1/3 Gi1/3
4 Gi1/4 Gi1/4 Gi1/4 Gi1/4 Gi1/4 Gi1/4 Gi1/4
5 Fa1/5 Fa1/5 Fa1/5 Fa1/5 Gi1/5 Gi1/5 Gi1/5
6 Fa1/6 Fa1/6 Fa1/6 Fa1/6 Gi1/6 Gi1/6 Gi1/6
7 Fa1/7 Fa1/7 Fa1/7 Fa1/7 Gi1/7 Gi1/7 Gi1/7
8 Fa1/8 Fa1/8 Fa1/8 Fa1/8 Gi1/8 Gi1/8 Gi1/8
9 Fa1/9 Fa1/9 Fa1/9 Gi1/9 Gi1/9 Gi1/9
10 Fa1/10 Fa1/10 Fa1/10 Gi1/10 Gi1/10 Gi1/10
11 Fa1/11 Fa1/11 Fa1/11 Gi1/11 Gi1/11 Gi1/11
12 Fa1/12 Fa1/12 Fa1/12 Gi1/12 Gi1/12 Gi1/12
27 SVI1 SVI1 SVI1 SVI1 SVI1 SVI1 SVI1
