490 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017

Appendix B Port Assignments for CIP Data

Stratix 5410

Port Assignments

Bit 1783-IMS28NDC, 1783-IMS28NAC, 1783-IMS28GNDC, 1783-IMS28GNAC, 1783-IMS28RDC,

1783-IMS28RAC, 1783-IMS28GRDC, 1783-IMS28GRAC

0 Any/All ports

1 Gi1/1

2 Gi1/2

3 Gi1/3

4 Gi1/4

5 Gi1/5

6 Gi1/6

7 Gi1/7

8 Gi1/8

9 Gi1/9

10 Gi1/10

11 Gi1/11

12 Gi1/12

13 Gi1/13

14 Gi1/14

15 Gi1/15

16 Gi1/16

17 Gi1/17

18 Gi1/18

19 Gi1/19

20 Gi1/20

21 Gi1/21

22 Gi1/22

23 Gi1/23

24 Gi1/24

25 Te1/25 or Gi1/25

26 Te1/26 or Gi1/26

27 Te1/27 or Gi1/27

28 Te1/28 or Gi1/28
