Parameter Description
Default Cost
CLI: lcr-default-cost
[RoutingRuleGroups_L
CRDefaultCost]
Determines whether routing rules in the Outbound IP Routing table
without an assigned Cost Group are considered a higher cost or lower
cost route compared to other matched routing rules that are assigned
Cost Groups.
 [0] Lowest Cost = If the device locates other matching LCR routing
rules, this routing rule is considered the lowest cost route and
therefore, it is selected as the route to use (default.)
 [1] Highest Cost = If the device locates other matching LCR routing
rules, this routing rule is considered as the highest cost route and
therefore, is not used or used only if the other cheaper routes are
unavailable.
Note: If more than one valid routing rule without a defined Cost Group
exists, the device selects the first-matched rule.
17.2.2.2 Configuring Cost Groups
The procedure below describes how to configure Cost Groups. Cost Groups are defined
with a fixed call connection cost and a call rate (charge per minute). Once configured, you
can configure Time Bands for each Cost Group. Up to 10 Cost Groups can be configured.
Note: The Cost Group table c
least-cost-routing cost-group.
 To configure Cost Groups:
1. Open the Cost Group Table page (Configuration tab > VoIP menu > Services
submenu > Least Cost Routing > Cost Group Table).
2. Click the Add button; the Add Record dialog box appears:
Figure 17-8: Cost Group Table - Add Record
3. Configure the parameters as required. For a description of the parameters, see the
table below.
4. Click Submit; the entry is added to the Cost Group table.
