AudioCodes Media 800 MSBR User Manual

Version 6.6 499 Mediant 800 MSBR
User's Manual 34. SAS Overview
34.2 SAS Routing
This section provides flowcharts describing the routing logic for SAS in normal and
emergency states.
34.2.1 SAS Routing in Normal State
The flowchart below displays the routing logic for SAS in normal state for INVITE
messages received from UAs:
Figure 34-5: Flowchart of INVITE from UA's in SAS Normal State
The flowchart below displays the routing logic for SAS in normal state for INVITE
messages received from the external proxy:
