Channel identification
Calling party number: '201'
Called party number: '102'
Sending complete
For CAS trace messages, the additional header "CAS Trace" is added below the
"AUDIOCODES DEBUG RECORDING" header, as shown in the example below:
AUDIOCODES DEBUG RECORDING
CAS Trace
Timer: 1145504439
From: DSP (0)
Current State: 7
Event: EV_DIAL_ENDED (15)
Next State: -1
Function Use: Unknown (-1)
Parameter 1: -1
Parameter 2: -1
Parameter 3: -1
Trunk Number: 3
BChannel Number: 23
Call Handle: 0
60.7 Capturing VoIP and Data-Router Network Traffic
You can capture VoIP and data-router network traffic by sending traces to the CLI or to a
file that is later sent to a TFTP server. The traffic can be captured using the following CLI
commands to start the debug capture process:
debug capture voip
debug capture data
