Parameter Description
Hotline Dial Tone Duration
CLI: hotline-dia-ltone-duration
[TargetOfChannel_HotLineTon
eDuration]
Defines the duration (in seconds) after which the destination
phone number is automatically dialed. This is applicable only if
set to Hotline).
The valid value is 0 to 60. The default is 16.
Note: You can configure this Hotline interval for all ports, using
the global parameter, HotLineToneDuration.
29.7 Configuring Caller Display Information
The Caller Display Information table allows you to define a caller identification string (Caller
ID) for FXS and FXO ports and enable the device to send the Caller ID to the IP when a
call is made. The called party can use this information for caller identification.
The device sends the configured caller ID in the outgoing INVITE message's From header.
For information on Caller ID restriction according to destination/source prefixes, see
'Configuring Source/Destination Number Manipulation' on page 303.
Notes:
• If an FXS port receives 'Private' or 'Anonymous' strings in the SIP From
header, the calling name or number is not sent to the Caller ID display.
• If Caller ID is detected on an FXO line (EnableCallerID = 1), it is used
instead of the Caller ID configured in this table.
• If you set the 'Caller ID/Name' parameter to the strings "Private" or
"Anonymous", Caller ID is restricted and the settings of the 'Presentation'
parameter is ignored.
• The Caller Display Information table can also be configured using the
table ini file parameter, CallerDisplayInfo or CLI command, configure voip
> gw analoggw caller-display-info.
 To configure Caller Display:
1. Open the Caller Display Information page (Configuration tab > VoIP menu > GW and
IP to IP > Analog Gateway > Caller Display Information).
Figure 29-7: Caller Display Information Page
2. Configure the table as required. For a description of the parameters, see the table
below.
3. Click Submit to apply your changes.
