User's Manual 40. WAN Access
40 WAN Access
The WAN Access menu allows you to configure your WAN (Internet) connection. When
subscribing to a broadband service, your Internet Service Provider (ISP) should provide
you information regarding the method by which you are connecting to the Internet.
The device can connect to the broadband service (WAN), using one of the following
methods:

Ethernet interface (copper or fiber cable), using connection methods such as
automatic IP address allocation or Point-to-Point Protocol over Ethernet (PPPoE). For
more information, see 'Configuring Ethernet WAN Interface' on page
535.

Symmetric High-Speed Digital Subscriber Line (SHDSL) connection using copper wire
pairs. The SHDSL WAN connection supports up to four copper wire pairs according to
G.991.2, acting as a remote-terminal CPE device. Both ATM and EFM modes are
supported. In the ATM mode, a variety of protocols are supported, including PPPoE,
PPPoA, and RFC 2684 in both bridged (Ethernet-over-ATM) and routed (IP-over-
ATM) variants. In the EFM mode, the SHDSL port functions as a logical Ethernet
device. For more information, see 'Configuring SHDSL WAN Interface' on page
537.
Note: The supported WAN connection methods depend on the installed Software
License Key. For installing a Software License Key, see 'Software License
Key' on page 644.
40.1 Configuring Ethernet WAN Interface
For Ethernet WAN interface, you can configure the device to use one of the following
methods for connecting to the Internet:

Manual IP address Ethernet connection

Automatic IP address Ethernet connection

Point-to-Point Protocol over Ethernet (PPPoE)

Layer 2 Tunneling Protocol (L2TP)
The type of connection should be as instructed by your ISP. If you do not have an Internet
connection or if you want to disable all existing connections, select No Internet
Connection from the 'Connection Type' drop-down list.
Once you have defined the basic WAN connection type (listed above and described in the
procedure below), you can configure advanced settings such as the WAN port's physical
attributes (link speed and duplex mode) and routing. The advanced configuration
parameters can be accessed using one of the following methods:

Clicking the Click here for Advanced Settings link as described in Step 3 below

Clicking the Edit icon in the Connections list, as described in 'Editing Existing
Connections' on page
614
