AudioCodes Media 800 MSBR User Manual

Version 6.6 727 Mediant 800 MSBR
User's Manual 60. Syslog and Debug Recordings
Parameter Description
Value
CLI: value
[LoggingFilters_Val
ue]
Defines the value of the selected filtering type in the 'Filter Type' parameter.
The value can be the following:
 A single value
 A range, using a hyphen "-" between the two values, e.g., "1-3"
 Multiple, non-contiguous values, using commas "," between each value,
e.g., "1,3,9"
 Trunks and FXO/FXS pertaining to a module, using the syntax module
number/port or port, for example:
 "1/2", means module 1, port 2
 "1/[2-4]", means module 1, ports 2 through 4
 Any to indicate all
 For IP trace expressions, see e 'Filtering IP Network Traces' on page
727
Syslog
CLI: syslog
[LoggingFilters_Sy
slog]
Enables Syslog messages for the defined logging filter:
 [0] Disable (default)
 [1] Enable
Capture Type
CLI: capture-type
[LoggingFilters_Ca
ptureType]
Enables debug recordings for the defined logging filter and defines what to
record:
 [0] None (default)
 [1] Signaling = Information related to signaling such as SIP signaling
messages, Syslog, and CDR.
 [2] Signaling & Media = Signaling and media (RTP/RTCP/T.38).
 [3] Signaling & Media & PCM = Signaling, media, and PCM (voice
signals from and to TDM).
 [4] PSTN trace = ISDN and CAS traces - applicable only for Trunk-
related filters.
60.4.1 Filtering IP Network Traces
You can filter Syslog and debug recording messages for IP network traces, by setting the
'Filter Type' parameter to IP Trace in the Logging Filters table. IP traces are used to record
any IP stream, according to destination and/or source IP address, or port and Layer-4
protocol (UDP, TCP or any other IP type as defined by http://www.iana.com
).
When the IP Trace option is selected, only the ‘Value’ parameter is applicable; the 'Syslog'
and 'Capture Type' parameters are not relevant. The 'Value' parameter configures the
Wireshark-like filtering expressions for your IP trace. The following Wireshark-like
expressions are supported:
Supported Wireshark-like Expressions for 'Value' Parameter
Expression Description
ip.src, ip.dst Source and destination IP address
ip.addr IP address - up to two IP addresses can be entered
ip.proto IP protocol type (PDU) entered as an enumeration value
(e.g., 1 is ICMP, 6 is TCP, 17 is UDP)
udp, tcp, icmp, sip, ldap, http, https Single expressions for protocol type
