opened page.
Burn
Saves parameter settings to flash memory (see 'Saving Configuration'
on page 624).
Device
Actions
Opens a drop-down list with frequently needed commands:
Load Configuration File: Opens the Configuration File page for
loading an ini file to the device (see 'Backing Up and Loading
Configuration File' on page 651).
Save Configuration File: Opens the Configuration File page for
saving the ini file to a folder on a computer (see 'Backing Up and
Loading Configuration File' on page 651).
Reset: Opens the Maintenance Actions page for performing
various maintenance procedures such as resetting the device (see
'Resetting the Device' on page 621).
Software Upgrade Wizard: starts the Software Upgrade wizard
for upgrading the device's software (see 'Software Upgrade
Wizard' on page 648).
Home
Opens the Home page (see 'Viewing the Home Page' on page 60).
Help
Opens the Online Help topic of the currently opened configuration
page (see 'Getting Help' on page 59).
Log off
Logs off a session with the Web interface (see 'Logging Off the Web
Interface' on page 60).
Note: If you modify a parameter that takes effect only after a device reset, after you
click the Submit
"Reset", as shown in the figure below. This is a reminder that you need to
later save your settings to flash memory and reset the device.
Figure 5-3: "Reset" Displayed on Toolbar
5.1.5 Navigation Tree
The Navigation tree is located in the Navigation pane and displays a tree-like structure of
menus pertaining to the selected tab on the Navigation bar. You can drill-down to the
required page item level to open its corresponding page in the Work pane.
The terminology used throughout this manual for referring to the hierarchical structure of
the tree is as follows:
