 To configure Syslog :
1. Open the Syslog Settings page (Configuration tab > System menu > Syslog
Settings).
Figure 60-1: Syslog Settings Page
2. Enable the Syslog feature by setting the 'Enable Syslog' to Enable.
3. Define the Syslog server using the 'Syslog Server IP Address' and 'Syslog Server Port'
parameters.
4. Configure the debug level using the 'Debug Level' parameter.
5. Under the 'Activity Types to Report ...' group, select the activities to report.
6. Click Submit to apply your changes.
60.3 Configuring Debug Recording
The device enables you to activate debug recording and send debug recording packets to
a defined capturing server. When the debug recording is activated, the device duplicates all
messages that are sent and/or received by it and then sends them to an external IP
address. The debug recording can be done for different types of traffic for example,
RTP/RTCP, T.38, ISDN, CAS, and SIP.
Debug recording is used for advanced debugging when you need to analyze internal
messages and signals. Debug recording is also useful for recording network traffic in
environments where hub or port mirroring is unavailable and for recording internal traffic
between two endpoints on the same device.
Notes:
• Debug recording is collected only on the device's OAMP interface.
• You can also save debug recordings to an external USB hard drive
connected to the device's USB port. For more information, see USB
Storage Capabilities on page 667.
