AudioCodes Media 800 MSBR User Manual

User's Manual 742 Document #: LTRT-12809
Mediant 800 MSBR

Remote Disconnections Count: Number of calls that were disconnected by the
remote side.

Average CPS: The average calls per second.

Test Status: Displays the status (brief description) as displayed in the 'Test Status'
field (see 'Starting, Stopping and Restarting Test Calls' on page
740).

Detailed Status: Displays a detailed description of the test call status::
• "Idle": The test call is currently not active.
• "Scheduled - Established Calls: <established calls>, ASR: <%>": The test call is
planned to run (according to 'Schedule Interval' parameter settings) and also
shows the following summary of completed test calls:
♦ Total number of test calls that were established.
♦ Number of successfully answered calls out of the total number of calls
attempted (ASR).
• "Running (Calls: <number of active calls>, ASR: <%>)": The test call has been
started (i.e., the Dial command was clicked) and shows the following:
♦ Number of currently active test calls.
♦ Number of successfully answered calls out of the total number of calls
attempted (Answer Seizure Ratio or ASR).
• "Receiving (<number of active calls>)": The test call has been automatically
activated by calls received for this configured test call endpoint from the
configured remote endpoint. When all these calls terminate, the status returns to
"Idle".
• "Terminating (<number of active calls>)": The Drop Call command has been
clicked to stop the test call and the test call is in the process of terminating the
currently active test calls.
• "Done - Established Calls: <established calls>, ASR: <%>": The test call has
been successfully completed (or was prematurely stopped by clicking the Drop
Call command) and shows the following:
♦ Total number of test calls that were established.
♦ Number of successfully answered calls out of the total number of calls
attempted (ASR).
Note: On the receiving side, when the first call is accepted in "Idle" state, statistics
are reset.
63.2 Configuring DTMF Tones for Test Calls
By default, no DTMF signal is played to an answered test call (incoming or outgoing).
However, you can enable this per configured test call in the Test Call table (see
'Configuring Test Call Endpoints' on page 737). If enabled, the default DTMF signal that is
played is "3212333". You can change this as described below.
Notes:
• The DTMF signaling type (e.g., out-of-band or in-band) can be
configured using the 'DTMF Transport Type' parameter. For more
information, see 'Configuring DTMF Transport Types' on page page 169.
• To generate DTMF tones, the device's DSP resources are required.
