Version 5.8 149 October 2009
SIP User's Manual 3. Web-Based Management
¾ To add Proxy servers and configure Proxy parameters:
1. Open the 'Proxy Sets Table' page (Configuration tab > Protocol Configuration
menu > Proxies/IpGroups/Registration submenu > Proxy Sets Table page item).
Figure 3-141: Proxy Sets Table Page
2. From the Proxy Set ID drop-down list, select an ID for the desired group.
3. Configure the Proxy parameters according to the following table.
4. Click the Submit button to save your changes.
5. To save the changes to flash memory, refer to ''Saving Configuration'' on page 237.
Table 3-13:
Proxy Sets Table Parameters
Parameter Description
Web: Proxy Set ID
EMS: Index
[ProxySet_Index]
The Proxy Set identification number.
The valid range is 0 to 5 (i.e., up to 6 Proxy Set ID's can be
configured). The Proxy Set ID #0 is used as the default Proxy Set,
and if defined is backward compatible to the list of Proxies from
earlier releases.
Note: Although not recommended, you can use both default Proxy
Set (ID #0) and IP Groups for call routing. For example, on the
'Hunt Group Settings' page (refer to ''Configuring the Trunk Group
Settings'' on page 222), yo
u can configure a Serving IP Group to
where you want to route specific HuntGroup's endpoints, while all
other device endpoints use the default Proxy Set. At the same, you
can also use IP Groups in the 'Tel to IP Routing' table (refer to
''Configuring the Tel to IP Routing Table'' on page 201) to
To Next Page
