SIP User's Manual 552 Document #: LTRT-12801
MP-500 MSBG
The Layer-2 Quality of Service parameters enables setting the values for the 3 priority bits
in the VLAN tag of frames related to a specific service class (according to the IEEE 802.1p
standard). The Layer-3 Quality of Service (QoS) parameters enables setting the values of
the DiffServ field in the IP Header of the frames related to a specific service class. The
following QoS parameters can be set:
Table 10-5: Quality of Service Parameters
Parameter Description
Layer-2 Class Of Service Parameter (VLAN Tag Priority Field)
DiffServ Table
[DiffServToVlanPriority]
This ini file table parameter allows you to configure
VLAN tag priorities.The format of this ini file is as follows:
[ DiffServToVlanPriority ]
FORMAT DiffServToVlanPriority_Index =
DiffServToVlanPriority_DiffServ,
DiffServToVlanPriority_VlanPriority;
[ \DiffServToVlanPriority ]
For example:
DiffServToVlanPriority 0 = 48, 7;
DiffServToVlanPriority 1 = 46, 6;
DiffServToVlanPriority 2 = 40, 6;
DiffServToVlanPriority 3 = 26, 4;
DiffServToVlanPriority 4 = 10, 2;
Notes:
 You can configure up to 64 VLAN tag priorities (i.e.,
indices 0-63).
 The valid range of the parameter DiffServ is 0-63.
 The valid range of the parameter VlanPriority is 0-7.
Layer-3 Class Of Service Parameters (TOS/DiffServ)
[PremiumServiceClassMediaDiffServ]
Sets the DiffServ for the Premium service class content
(media traffic)
[PremiumServiceClassControlDiffServ]
Sets the DiffServ for the Premium service class content
(control traffic)
[GoldServiceClassDiffServ]
Sets the DiffServ for the Gold service class content
(streaming traffic)
[BronzeServiceClassDiffServ]
Sets the DiffServ for the Bronze service class content
(OAMP traffic)
The mapping of an application to its CoS and traffic type is shown in the table below:
Table 10-6: Traffic / Network Types and Priority
Application Traffic / Network Types Class-of-Service (Priority)
Debugging interface
Management Bronze
Telnet
Management Bronze
Web server (HTTP)
Management Bronze
SNMP GET/SET
Management Bronze
Web server (HTTPS)
Management Bronze
