Version 5.8 47 October 2009
SIP User's Manual 3. Web-Based Management
3.2.8.6 Deleting a Scenario
You can delete the Scenario by using the Delete Scenario File button, as described in the
procedure below:
¾ To delete the Scenario:
1. On the Navigation bar, click the Scenarios tab; a message box appears, requesting
you to confirm:
Figure 3-19: Scenario Loading Message Box
2. Click OK; the Scenario mode appears in the Navigation tree.
3. Click the Delete Scenario File button; a message box appears requesting
confirmation for deletion.
Figure 3-20: Message Box for Confirming Scenario Deletion
4. Click OK; the Scenario is deleted and the Scenario mode closes.
Note:
You can also delete a Scenario using the following alternative methods:
• Loading an empty dat file (refer to ''Loading a Scenario to the Device'' on
page 46).
• Loading an ini file with the ScenarioFileName parameter set to no value
(i.e., ScenarioFileName = "").
