SIP User's Manual 222 Document #: LTRT-12801
MP-500 MSBG
3.4.5.12.2 Configuring Hunt Group Settings
The 'Hunt Group Settings' page allows you to configure up to 24 Hunt Groups. These Hunt
Groups can be assigned ID's between 1 and 99. The device's channels can be conveniently
assigned to these Hunt Groups in the 'Trunk Group Table' page (refer to “Configuring the
Trunk Group Table” on page 220).
The '
Hunt Group Settings' page is also used to select the method for which IP-to-Tel calls
are assigned to channels within each Hunt Group. If no method is selected (for a specific
Hunt Group), the setting of the global parameter ChannelSelectMode applies. In addition,
this page defines the method for registering Hunt Groups to selected Serving IP Group IDs
(if defined).
Note: You can also configure the Hunt Group Settings table using the ini file table
parameter TrunkGroupSettings (refer to ''Number Manipulation and Routing
Parameters'' on page 408).
¾ To configure the Hunt Group Settings table:
1. Open the 'Hunt Group Settings' page (Configuration tab > Protocol Configuration
menu > Hunt Group submenu > Hunt Group Settings page item).
Figure 3-174: Hunt Group Settings Page
2. From the 'Routing Index' drop-down list, select the range of entries that you want to
edit (up to 24 entries can be configured).
3. Configure the Hunt Group according to the table below.
4. Click the Submit button to save your changes.
5. To save the changes to flash memory, refer to ''Saving Configuration'' on page 237.
An example i
s shown below of a REGISTER message for registering endpoint "101" using registration
Per Endpoint mode. The "SipGroupName" in the request URI is taken from the IP Group table.
REGISTER sip:SipGroupName SIP/2.0
Via: SIP/2.0/UDP 10.33.37.78;branch=z9hG4bKac862428454
From: <sip:101@GatewayName>;tag=1c862422082
To: <sip:101@GatewayName>
Call-ID: 9907977062512000232825@10.33.37.78
CSeq: 3 REGISTER
Contact: <sip:101@10.33.37.78>;expires=3600
Expires: 3600
User-Agent: Audiocodes-Sip-Gateway/v.5.80A.008.002
Content-Length: 0
