Version 5.8 191 October 2009
SIP User's Manual 3. Web-Based Management
3.4.5.8.6 Configuring the IP to IP Inbound Manipulation Table
The 'IP to IP Inbound Manipulation Table' page allows you to configure up to 100
manipulation rules for SIP URI user part (source and destination) manipulations.
Manipulation rules in the table are located according to the source IP Group, and source
and destination host and user prefixes.
Manipulated destination URI user part are performed on the following SIP headers:
Request URI, To, and Remote Party ID (if exists). Manipulated source URI user part are
performed on the following SIP headers: From, P-Asserted (if exists), P-Preferred (if exists),
and Remote Party ID (if exists).
Notes:
• For a specific manipulation rule to be effective, the incoming SIP dialog
must match the characteristics configured for that rule (i.e., source IP
Group and source/destination user/host prefixes).
• The manipulation rules apply to the SIP INVITE, OPTIONS, and
SUBSCRIBE messages (not REGISTER messages).
• The 'IP to IP Inbound Manipulation' table can also be configured using
the ini file table parameter IPInboundManipulation (refer to ''SBC
Parameters'' on page 383).
• Host name (source and destination) manipulations are configured in the
'IP Group' table. These manipulations are simply host name substitutions
with the names defined for the source and destination IP Groups
respectively.
¾ To configure the IP to IP Inbound Manipulation table:
1. Open the 'IP to IP Inbound Manipulation Table' page (Configuration tab > Protocol
Configuration menu > SBC submenu > IP to IP Inbound Manipulation Table).
Figure 3-160: IP2IP Inbound Manipulation Page
2. Add an entry and then configure it according to the table below.
3. Click the Apply button to save your changes.
4. To save the changes to flash memory, refer to ''Saving Configuration'' on page 237.
