Version 5.8 449 October 2009
SIP User's Manual 8. Auxiliary Configuration Files
8.5 User Information File
The User Information file is a text file that maps PBX extensions connected to the device to
global IP numbers. In this context, a global IP phone number (alphanumerical) serves as a
routing identifier for calls in the 'IP world'. The PBX extension uses this mapping to emulate
the behavior of an IP phone.
Note: The mapping mechanism is disabled by default and must be activated using
the parameter EnableUserInfoUsage (refer to ''Advanced Parameters'' on
page 168).
The maximum size of the file is 10,800 bytes. Each line in the file represents a mapping rule
of a single PBX extension. Up to rules can be configured. Each line includes five items
separated with commas. The items are described in the table below:
Table 8-1: User Information Items
Item Description Maximum Size
(Characters)
PBX extension #
The relevant PBX extension number. 10
Global phone #
The relevant global phone number. 20
Display name
A string that represents the PBX extensions for the
Caller ID.
30
Username
A string that represents the user name for SIP
registration.
40
Password
A string that represents the password for SIP
registration.
20
An example of a User Information file is shown in the figure below:
Figure 8-1: Example of a User Information File
Note: The last line in the User Information file must end with a carriage return (i.e.,
by pressing the <Enter> key).
