SIP User's Manual 560 Document #: LTRT-12801
MP-500 MSBG
Notes:
• Lines that begin with a semicolon are considered a remark and are
ignored.
• The Multiple Interface table configuration using the ini file must have the
prefix and suffix to allow AudioCodes INI File parser to correctly
recognize the Multiple Interface Table.
The following sections show some examples of selected network configurations, and their
matching ini file configuration.
Example 1: Single Interface Configuration - Multiple Interface table with a single
interface for OAMP, Media and Control applications:
Table 10-9: Multiple Interface Table - Example 1
Index Application Interface IP Address
Prefix
Length
Default
Gateway
VLAN
ID
Interface
Name
0
OAMP,
Media &
Control
IPv4 192.168.85.14 16 192.168.0.1 1 myInterface
VLANS are not required and the 'Native' VLAN ID is irrelevant. Class of Service parameters
may have default values. The required routing table features two routes:
Table 10-10: Routing Table - Example1
Destination Prefix Length Subnet Mask Gateway Interface Metric
201.201.0.0 16
192.168.0.2 0 1
202.202.0.0 16
192.168.0.3 0 1
The DNS/NTP applications may have their default application types. This example's
matching ini file is shown above. However, since many parameter values equal their default
values, they can be omitted. The ini file can be also written as follows:
; Interface Table Configuration:
[InterfaceTable]
FORMAT InterfaceTable_Index = InterfaceTable_ApplicationTypes,
InterfaceTable_InterfaceMode, InterfaceTable_IPAddress,
InterfaceTable_PrefixLength, InterfaceTable_Gateway,
InterfaceTable_VlanID, InterfaceTable_InterfaceName;
InterfaceTable 0 = 6, 10, 192.168.85.14, 16, 192.168.0.1, 1, myAll;
[\InterfaceTable]
; Routing Table Configuration:
RoutingTableDestinationsColumn = 201.201.0.0, 202.202.0.0
RoutingTableDestinationPrefixLensColumn = 16, 16
RoutingTableGatewaysColumn = 192.168.0.2, 192.168.0.3
RoutingTableInterfacesColumn = 0, 0
RoutingTableHopsCountColumn = 1, 1
Example 2: Three Interfaces, one for each application exclusively - the Multiple
Interface table is configured with three interfaces, one exclusively for each application type:
one interface for OAMP applications, one for Call Control applications, and one for RTP
Media applications:
