AudioCodes mediapack MP-500 User Manual

Version 5.8 295 October 2009
SIP User's Manual 6. Configuration Parameters Reference
Parameter Description
Web: Gateway IP Address
EMS: Next Hop
[RoutingTableGatewaysColumn]
The IP address of the router (next hop) to which the
packets are sent if their destination matches the rules
in the adjacent columns.
Notes:
 For this parameter to take effect, a device reset is
required.
 The Gateway address must be in the same subnet
as configured on the 'Multiple Interface Table' page
(refer to ''Configuring the Multiple Interface Table''
on page 58).
Web: Metric
EMS: Primary Routing Metric
[RoutingTableHopsCountColumn]
The maximum number of times a packet can be
forwarded (hops) between the device and destination
(typically, up to 20).
Notes:
 For this parameter to take effect, a device reset is
required.
 This parameter must be set to a number greater
than 0 for the routing rule to be valid. Routing
entries with Hop Count equals 0 are local routes set
automatically by the device.
Web: Interface
EMS: Interface Index
[RoutingTableInterfacesColumn]
Specifies the interface (network type) to which the
routing rule is applied.
 [0] = OAMP (default).
 [1] = Media.
 [2] = Control.
For detailed information on the network types, refer to
''Configuring the Multiple Interface Table'' on page 58.
Not
e: For this parameter to take effect, a device reset
is required.
6.1.4 Quality of Service Parameters
The Quality of Service (QoS) parameters are described in the table below. The device
allows you to specify values for Layer-3 priorities by assigning values to the following
service classes:
 Network Service class – network control traffic (ICMP, ARP)
 Premium Media service class – used for RTP Media traffic
 Premium Control Service class – used for Call Control traffic
 Gold Service class – used for streaming applications
 Bronze Service class – used for OAMP applications
The Layer-2 QoS parameters enables setting the values for the 3 priority bits in the VLAN
tag of frames related to a specific service class (according to the IEEE 802.1p standard).
The Layer-3 QoS parameters enables setting the values of the DiffServ field in the IP
Header of the frames related to a specific service class.
