SIP User's Manual 504 Document #: LTRT-12801
MP-500 MSBG
9.7.2 FXO Operations for Tel-to-IP Calls
The FXO device provides the following FXO operating modes for Tel-to-IP calls:
îš„ Automatic Dialing (refer to ''Automatic Dialing'' on page 504)
îš„ Colle
cting Digits Mode (refer to ''Collecting Digits Mode'' on page 504)
îš„ Ring
Detection Timeout (refer to ''Ring Detection Timeout'' on page 507)
îš„ FXO Supple
mentary Services (refer to ''FXO Supplementary Services'' on page 505)
• Hold/Trans
fer Toward the Tel side
• Hold/Transfer Toward the IP side
• Blind Transfer to the Tel side
9.7.2.1 Automatic Dialing
Automatic dialing is defined using the ini file parameter table TargetOfChannel (refer to
Analog Telephony Parameters) or the embedded Web server's 'Automatic Dialing' screen
(refer to ''Automatic Dialing'' on page 213).
The SIP call flow diagram below illustrates Automatic Dialing.
Figure 9-35: Call Flow for Automatic Dialing
