SIP User's Manual 242 Document #: LTRT-12801
MP-500 MSBG
Figure 3-189: Load a CMP File
Note: At this stage, you can quit the Software Update Wizard, by clicking Cancel
, without requiring a device reset. However, once you start uploading a
cmp file, the process must be completed with a device reset.
4. Click the Browse button, navigate to the cmp file, and then click Send File; the cmp
file is loaded to the device and you're notified as to a successful loading.
5. Click one of the following buttons:
•
Reset; the device resets with the newly loaded cmp, utilizing the existing
configuration and auxiliary files.
•
Next; the 'Load an ini File' wizard page opens.
Note that as you progress by clicking Next, the relevant file name corresponding to the
applicable Wizard page is highlighted in the file list on the left.
To Next Page
