SIP User's Manual 278 Document #: LTRT-12801
MP-500 MSBG
The MG Tree is a hierarchical tree-like structure that lists all the devices managed by EMS.
The tree includes the following icons:
îš„ Globe
: highest level in the tree, from which a Region can be added.
îš„ Region
: defines a group (e.g., geographical location) to which devices can be
added. If you click a Region that is defined with devices (MG's), the Configuration pane
(see figure above) displays a list of all the devices pertaining to the Region.
îš„ MG
: defines the device. This is the lowest level in the tree. If you click an MG icon,
the Configuration pane (see figure above) displays a graphical representation of the
device's chassis.
5.2 Adding the Device in EMS
Once you have defined the IPSec communication protocol for communicating between
EMS and the device, and configured the device's IP address (refer to the device's
Installation Manual), you can add the device in the EMS.
Adding the device to the EMS includes the following main stages:
a. Adding a Region
b. Adding the device's software version file (cmp) to the EMS Software Manager
c. Defining the device's IP address (and other initial settings)
For installing the EMS software, refer to the EMS User's Manual.
¾ To initially setup the device in EMS:
1. Start the EMS by double-clicking the EMS Client icon, or from the Start menu,
point to Programs, to EMS Client, and then click EMS CLient; the Login Screen
appears:
Figure 5-2: EMS Login Screen
2. Enter the login name and password, and the EMS server's IP address, and then click
OK.
