147 HD96-24-CC-TP User Manual
Item Control Function
11 Audition A sample is triggered to test reverb characteristic.
12 MIX control Controls the dry/wet output mix and ranges from 0% to 100%, respectively.
13 Diusion Control
Reducing diusion creates more discrete echoes, for vocals and other sustained sounds, reduced diusion can give smooth
reverberation that doesn’t overpower the source and maintains clarity.
14 Contour Time control Increases the centre part of the reverbs tail in comparison to the rest of the reverb.
15 Modulation control To create more variation in reverb sounds, modulation adds subtle changes to the reverb characteristics.
16 POWER button Turns on the Reverb eect.
Hall Reverb
The hall reverb simulates the response of a real concert hall adding a sense of space to the source material with less initial density than a chamber reverb. The slower
build-up of reections and generally longer decay times associated with this type of algorithm allows for increased clarity of the source, while oering a richer, more
lush overall sound that is less dense in character.
This eect features contour controls to adjust the envelope shape during the initial portion of the reverb tail and also the time over which the reection density increases.
Reective surface materials and air absorption properties can be simulated by adjusting the high and low frequency cut amount and high frequency damping.
Low frequency decay and cross-over parameters allow relative control over the low band reverb tail length. This can be used to either simulate real room responses,
which often have a longer decay time at low frequencies or alternatively can be useful to reduce low frequency energy in a live environment where it may already be
present due to the natural reverberation of the venue.
Item Control Function
1 IN Level meter LED Metering shows input level.
2 Pre Delay control Controls the amount of delay (in milliseconds) between the initial signal and the onset of reverberation.
3 LF Cut control Control that adjusts the Low Frequency cut from 10 Hz to 500 Hz.
4 LF X-over control Changes the X-Over point of the reverb from 20 Hz to 500 Hz.
5 LF Decay control Adjusts the length of the low frequency section of the reverb in compression to the rest of the reverb tail.
6 HF Cut control Control that adjusts the High Frequency cut from 0.2 kHz to 20 kHz.
7 HF Damp control Dampens the HF to produce a darker sounding reverb. Settings from 1 kHz to 20 kHz.
