287 HD96-24-CC-TP User Manual
Equaliser Multiple Select view
If two or more paths are selected the Equaliser Page allows multiple paths to be edited as one. For example, select a monitor speaker aux POP group and take a little 1
kHz out of every mix.
1. Select 2 or more paths to edit at once.
2. Each path’s EQ will be displayed in the window. Only 16 paths will be displayed if more than 16 paths are selected. The other paths are still selected even though
not in view and changes will be made to all selected paths.
3. Select the band you wish to change.
4. Absolute changes all values to the same value as set by the control.
5. Relative keeps any dierences between levels intact. For example, add +3 dB of gain to the bass band will add +3 dB to any cut or boost on the selected paths. If a
kick drum was at +2 dB in the bass band it would become + 5dB, if a snare had a cut in the bass band at -2 dB it would become +1 dB.
6. Pass thru allows EQ changes to be made once the control “Passes through” the current set level, then follows the control as it changes.
The vertical assignable controls are available to the right of the screen. They are controlled in the same manner as Solo View.
