34 HD96-24-CC-TP User Manual
Channel Detail Area
The familiar looking Channel Detail Area is used for hands on control with sections for Cong, Equaliser, Dynamics, Phones, Talk, Solo, Monitor, Main Bus and Master.
This area makes using the surface easy to use with a familiar analogue feel. The 4 x Change Over (C/O) buttons for Master, Mono, Monitor A and Monitor B assign the
control to the fader below for quick control.
Front and rear panel connections
The surface has connector panels on both the front and rear. The front connector panel to the right of the GUI has an XLR socket and a USB sockets for connecting a talk
mic and USB device, respectively. Under the armrests at either side there are two 6.35 mm headphone sockets which link to Mon A and Mon B respectively.
