Midas U Phase
The phaser eect consists of one, or if congured for dual operation, two stereo phasers connected in serial/parallel according to mode setting. This eect is fabulous
at adding beatlesque creative movement to vocals.
Item Control Function
1 Modulation meter A Pair of 25 orange LED segments are used to show the modulation on each channel.
2 Input meters Two rows of 24 LEDs, which show input metering.
3 Rate control (channels 1 and 2) Controls the rate of modulation in Hz. Range is from 0 Hz and 40 Hz.
4 Manual control (channels 1 and 2) Sets the sweep oset for performing manual sweep. Range is from 500 Hz to 24 kHz.
5 HI EQ control
Adjusts the amount of HF (high EQ) cut or boost applied to the eect output (in dB). Range is from
-12 dB to +12 dB with 0 dB at top centre.
6 LO EQ control
Adjusts the amount of LF (low EQ) cut or boost applied to the eects output (in dB). Range is from
-12 dB to +12 dB with 0 dB at top centre.
7 Mode button
Selects the operating mode: single; dual series; dual parallel; linked series; or linked parallel. When
linked, modulation of phasers 1 and 2 are linked.
8 Sweep button Sets the modulation waveform shape.
9 Stages button Selects the number of all pass stages, which sets the number of notches in the frequency response.
10 Depth control
Controls the intensity of the eect by setting the depth of phasing lters. Range is from 0% to
100%.
11 Spin control Adjusts the amount of relative phase of left/right modulation. Range is from 0% to 100%.
12 Feedback control
Adjusts the amount of negative/positive feedback applied to the delay. Controls the number of
repeats. Range is from -100% to +100%, with 0% at top dead centre.
13 Blend control Adjusts the mix between dry (0%) wet (100%).
14 Gain control knob Adjusts the signal level (dB). Range is -±20dB, with 0dB at top centre.
15 Out meters Two rows of 24 LEDs, which show output metering.
16 Power button Switch the Phaser eect on and o. Illuminates red to indicate eect is on.
