205 HD96-24-CC-TP User Manual
Playlists
A playlist is a way of organising scenes into various dierent orders, for example if a band changes their set list you can create a new playlist for that setlist. This give
you the ability to go back to a previous playlist if required. You can create as many playlists as you like.
To create a play list:
1. After creating and loading a show press New in the Playlists area.
2. The currently selected playlist is highlighted in green.
3. Press Open to load the currently selected Playlist
4. Press Rename in order to edit the name.
5. Press Delete to remove the playlist.
6. This area displays a list of scenes in the current open playlist. Playlist order can be changed by holding onto the scene you wish to move until it wiggles, then move
it up and down in the list.
7. This area displays All Scenes available within the currently loaded show.
8. This area show the number of events stored in that scene.
9. This arrow moves the scene into the currently open playlist at the end.
10. This X removes the scene from the playlist (it does not delete the scene)
11. Remove All clears all scenes from the current playlist.
12. To delete a scene, select the scene you wish to delete in the All Scenes window. Then press and hole the Delete button to erase the scene permanently.
Safes
Important: Safes are intended for emergency use only and are not to be confused with scope (see Chapter 20 Show Editor (Scope). Safes are incorporated into the
HD96-24 system to prevent certain controls from being recalled with a scene. Safe activation and status are provided via the GUI only.
There are 7 types of channel safe: Gate, Comp, EQ, Filters, Cong, Mute and Main Bus. Although some types of safes are channel-specic, any channel can be made safe
from o-channel mute, fader and automation control. Also, solo (for monitor areas A and B) is always out of scene on any channel.
