149 HD96-24-CC-TP User Manual
Item Control Function
13 MIX control Controls the DRY/WET output mix and ranges from 0% to 100%, respectively.
14 Audition A sample is triggered to test reverb characteristic.
15 OUT Level meter
OUTPUT meters, which comprise a dual-column peak reading LED meters, ranging from -30 dB to 18 dB in 3 dB steps. Each
column consists of 14 coloured LEDs. The red LED illuminates at 3 dB before the clipping point, which also provides an over-range
warning for the arithmetical processor.
Delays:
Midas Delay
The delay eect provides simple delay line eect. Delay times can be specied manually. To use the surface tap button, switch on Use Global and BPM Sync. Around 5
taps provides the most accurate tempo timing setting.
There are two models of delay, Analogue and Digital. The two dierent eect styles become more apparent when modulation is applied to the delay tail.
Item Control Function
1 Close button For closing the eect.
2 Tempo control Adjusts the tempo in tempo mode. Range is from 60 to 360 beats per minute (bpm).
3 Use Global button Follows the global tap tempo when active and allows the surface tap button to be used.
4 Range button
Selects one of three delay time ranges (1-25 ms, 10-200 ms or 82-1640 ms). Value is displayed
immediately below/above button.
5 BPM Sync button Activates BPM (TAP TEMPO) mode.
6 Link button Links delay time of left and right channels.
7 Time Left channel delay time control For entering the desired delay time in ms.
8 Time Right channel delay time control For entering the desired delay time in ms.
9 Pan control Pans channel between L (left) and R (right) outputs.
10 Level control Adjusts the output level. Range is from o to +10 dB.
11 Feedback control
Adjusts the amount of negative/positive feedback applied to delay. Controls the number of repeats.
Range is from -100% to +100%.
12 Blend control Adjusts the feedback blend from norm to cross.
13 Mod Depth L & R in modulation area Adjusts depth of delay modulation. Range is from 0 to 100.
14 HF Depth in modulation area Adjusts depth of delay modulation. Range is 0 to 100, with 50 at top dead centre.
15 Mod Rate in modulation area Adjusts rate of delay modulation. Range is between 0.001 Hz and 10 Hz.
16 Mix control knob Adjusts the mix between dry (0%) wet (100%).
