284 HD96-24-CC-TP User Manual
Chapter 33. Manchino (Multi Edit Page)
The denition of Manchino (Manchester Cappuccino):
1. Four shots of espresso with a dash of foam used to keep engineers focused in the creation of the Midas HD96-24 system.
2. The name of the multi edit page that revolutionises how engineers interact with a mixing console.
The Manchino page is the heart of the HD96-24 system and can be used to do countless tasks and make complex changes possible but with only a few short touches.
About the Manchino Page.
The Manchino Page has 8 separate tabbed pages (Linecheck, Equaliser, Compressor, Gate, Patching, Naming, Sends and Safes/Scope) which control various functions
throughout the console. Tabs for Inputs, Outputs and Matrices/Masters plus VCA and POP group navigation allow multiple channel selections at one.
In this chapter each page will be described in depth. All pages use the same channel selection system for navigation which is described in the rst Linecheck page.
There are some dierences between Input, Auxes and Matrices & Masters controls such as Auxes, Matrices & Masters don’t have HPF & LPF or a gate. Many of the
functions, such as 48v or EQ On have a press and hold second function which lets you see which paths are currently in the active or On state. Long press functions are
listed below:
LINECHECK EQUALISER COMPRESSOR GATE SAFES
48v EQ ON COMP ON GATE ON ALL
Ø FILTER ON FILTER ON GATE
HP ON COMP
LP ON EQUALISER
STEREO FILTERS
CONFIG
MUTE
MAIN BUS
1. Long press a function button to see the status on the paths to the left side.
2. In this example functions highlighted in red are showing that 48v is on.
Manchino operates in two ways:
A solo channel inspector type mode where a single path’s controls can be looked and changed in one place whist being heard in the solo bus.
Multiple select mode allows various groups of channels to be selected and controlled in several dierent ways.
