Additional Graphing Topics 483
4. Press ¸ to close the dialog box.
The Two-Graph Screen
The Two-Graph ScreenThe Two-Graph Screen
The Two-Graph Screen
A two-graph screen is similar to a regular split screen.
Page 2:
• Split 1 App = application for top or left side
•
Split 2 App = application for bottom or right
side
•
Graph 2 = Graph mode for bottom or right side
• Split Screen Ratio = relative sizes of the two
sides (Voyage™ 200 only)
Graph 2: right or
bottom side
Graph mode of active graph
Graph 1: left or
top side
Thick border
indicates active
graph side
Active graph side: GR#1 or GR#2
