Configuring Service Assurance Agent SAA Defaults

OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 38-2

SAA Defaults

There are no SAAs created by default. However, when an agent is configured, the following default

parameter values are applied unless otherwise specified:

Parameter Description Command Default Value/Comments

Time interval between test iterations saa interval 150 minutes

SAA description saa descr “DEFAULT”

SAA jitter threshold saa jitter-threshold 0 (disabled)

SAA round-trip-time threshold saa rtt-threshold 0 (disabled)
