Configuring QoS Using Map Groups
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 26-61
How Map Groups Work
When mapping from 802.1p to 802.1p, the action results in remapping the specified values. Any values
that are not specified in the map group are preserved. In this example, a map group is created for 802.1p
bits.
-> policy map group Group2 1-2:5 4:5 5-6:7
-> policy action Map1 map 802.1p to 802.1p using Group2
The to and from values are separated by a colon (:). If traffic with 802.1p bits comes into the switch and
matches a policy that specifies the Map1 action, the bits are remapped according to Group2. If the
incoming 802.1p value is 1 or 2, the value is mapped to 5. If the incoming 802.1p value is 3, the outgoing
value is 3 (the map group does not specify any mapping for a value of 3). If the incoming 802.1p value is
4, the value is mapped to 5. If the incoming 802.1p value is 5 or 6, the value is mapped to 7.
When mapping to a different type of value, however (ToS/DSCP to 802.1p), any values in the incoming
flow that matches the rule but that are not included in the map group is zeroed out. For example, the
following action specifies the same map group but instead specifies mapping 802.1p to ToS:
-> policy action Map2 map tos to 802.1p using Group2
In this case, if ToS traffic comes into the switch and matches a policy that specifies the Map2 action, the
ToS value is mapped according to Group2 if the value is specified in Group2. If the incoming ToS value
is 2, the value is mapped to 5; however, if the incoming value is 3, the switch maps the value to zero
because there is no mapping in Group2 for a value of 3.
Creating Map Groups
To create a map group, use the policy action map command. For example, to create a map group called
tosGroup, enter:
-> policy map group tosGroup 1-2:5 4:5 5-6:7
The to and from values are separated by a colon (:). For example, a value of 2 is mapped to 5.
The remapping group can then be associated with a rule through the policy action command. In this
example, a policy condition called Traffic has already been configured.
-> policy action tosMap map tos to 802.1p using tosGroup
-> policy rule r3 condition Traffic action tosMap
To delete mapping values from a group, use no and the relevant values:
-> policy map group tosGroup no 1-2:4
The specified values are deleted from the map group at the next qos apply.
To delete a map group, use the no form of the policy map group command. The map group must not be
associated with a policy action. For example:
-> no policy map group tosGroup
Note. Ports on which the flow is mapped must be a trusted port; otherwise the flow is dropped.
Note. Map group configuration is not active until the qos apply command is entered.
