Policy Server Defaults

Defaults for the policy server command are as follows:

Description Keyword Default

The port number for the server port 389 (SSL disabled)

636 (SSL enabled)

Priority value assigned to a server, used to

determine search order

preference 0 (lowest)

Whether a Secure Socket Layer is configured

for the server

ssl | no ssl no ssl
