Configuring Multiple VRF VRF Interaction With Other Features
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 16-11
VRF Interaction With Other Features
This section contains important information about how other OmniSwitch features interact with VRF
instances. Refer to the specific chapter for each feature to get more detailed information about how to
configure and use the feature.
All OmniSwitch AOS applications fall into one of the following three categories in relation to the Multiple
VRF feature:
• VRF Aware. Switch applications that are configurable independently and separately within one or
more VRF instances. All VRF aware applications can be enabled or disabled on each VRF instance.
• Default VRF. Switch applications that are VRF aware but only use the default VRF instance when IP
connectivity is needed; these applications are not supported across multiple VRF instances.
• Non-VRF Aware. Switch applications that have no association with any VRF instance, even the
default instance. Note that configuration of this type of application is only allowed when the default
instance is the active CLI context.
Refer to the following table to determine the VRF association for a specific switch application.
Applications that do not appear in this table are non-VRF aware.
The following subsections provide additional information related to Multiple VRF interaction with
specific applications.
AAA RADIUS/TACACS+/LDAP Servers
• AAA RADIUS or TACACS+ or LDAP server can be configured on any VRF instance including the
default VRF instance. However, all of the servers (for example, all the RADIUS servers) must reside
on the same VRF instance.
VRF-Aware Applications Default VRF Applications
AAA RADIUS Server
BFD
BGPv4
BGPv6
DVMRP
FTP Server
GRE Tunnels
HTTP Server
IPv4/ARP
IP-IP Tunnels
IPv6/NDP
IPv6 Configured Tunnels
IS-ISv4
IS-ISv6
LDAP Server
NTP
OSPFv2
OSPFv3
PIM-DM (IPv4)
PIM-SM (IPv4)
Ping
QoS VRF Policies
RIPv2
RIPng
Route Map Redistribution
SSH Server (SSH, SFTP,
SCP)
SNMP (Agent)
Static routes
TACACS+ Server
Telnet Server
Traceroute
UDP/DHCP Relay
DHCPv6 Relay
DHCP Client
VRRPv2
VRRPv3
Webview
AAA
DNS Client
EMP access
FTP Client
Policy Based Routing
Router Discovery Protocol
SFTP
SSH Client
Telnet Client
Trap Manager
VXLAN
IPv6 6to4 Tunnel
