Configuring Static Link Aggregation Quick Steps for Configuring Static Link Aggregation
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 8-3
Quick Steps for Configuring Static Link
Aggregation
Follow the steps below for a quick tutorial on configuring a static aggregate link between two switches.
Additional information on how to configure each command is given in the subsections that follow.
1 Create the static aggregate link on the local switch with the linkagg static agg size command. For
example:
-> linkagg static agg 1 size 4
2 Assign all the necessary ports with the linkagg static port agg command. For example:
-> linkagg static port 1/1-4 agg 1
3 Create a VLAN for this static link aggregate group with the vlan members command. For example:
-> vlan 10 members port 1
4 Create the equivalent static aggregate link on the remote switch with the linkagg static agg size
command. For example:
-> linkagg static agg 1 size 4
5 Assign all the necessary ports with the linkagg static port agg command. For example:
-> linkagg static port 1/9-12 agg 1
6 Create a VLAN for this static link aggregate group with the vlan members command. For example:
-> vlan 10 members default 1
Note. Optional. You can verify your static link aggregation settings with the linkagg range command
along with the agg keyword and aggregate group ID. For example:
-> show linkagg agg 1
Static Aggregate
SNMP Id : 40000001,
Aggregate Number : 1,
SNMP Descriptor : Omnichannel Aggregate Number 1 ref 40000001 size 4,
Name : ,
Admin State : ENABLED,
Operational State : UP,
Aggregate Size : 4,
Number of Selected Ports : 4,
Number of Reserved Ports : 4,
Number of Attached Ports : 4,
Primary Port : 1/1
You can also use the show linkagg port port command to display information on specific ports. See
“Displaying Static Link Aggregation Configuration and Statistics” on page 8-11 for more information on
the show commands.
