Configuring QoS Classification
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 26-8
To configure individual ports as trusted, use the qos port trusted command with the desired slot/port
number. For example:
-> qos port 3/2 trusted
The global setting is active immediately; however, the port setting requires qos apply to activate the
change. See “Applying the Configuration” on page 26-71 for more information.
To display information about QoS ports, such as whether or not the port is trusted, use the show qos port
command. For example:
-> show qos port
Slot/ Default Default Bandwidth DEI
Port Active Trust P/DSCP Classification Physical Ingress Egress Map/Mark Type
-----+------+-----+------+---------------+--------+-------+-------+---------+-------------
1/1 No No 0/ 0 DSCP 0K - - No / No ethernet
1/2 Yes No 0/ 0 DSCP 1.00G - - No / No ethernet-1G
1/3 No No 0/ 0 DSCP 0K - - No / No ethernet
1/4 No No 0/ 0 DSCP 0K - - No / No ethernet
1/5 No No 0/ 0 DSCP 0K - - No / No ethernet
1/6 No No 0/ 0 DSCP 0K - - No / No ethernet
1/7 No No 0/ 0 DSCP 0K - - No / No ethernet
1/8 No No 0/ 0 DSCP 0K - - No / No ethernet
1/9 No No 0/ 0 DSCP 0K - - No / No ethernet
1/10 No No 0/ 0 DSCP 0K 50K - No / No ethernet
1/11 No *Yes 0/ 0 *802.1P 0K - - No / No ethernet
1/12 No *Yes 0/ 0 *802.1P 0K - - No / No ethernet
Using Trusted Ports With Policies
Whether or not the port is trusted is important if you want to classify traffic with 802.1p bits. If the policy
condition specifies 802.1p, the switch must be able to recognize 802.1p bits. (Note that the trusted port
must also be 802.1Q-tagged). The 802.1p bits can be set or mapped to a single value using the policy
action 802.1p command.
In the following example, the qos port command specifies that port 2 on slot 3 are able to recognize
802.1p bits. A policy condition (Traffic) is then created to classify traffic containing 802.1p bits set to 4
and destined for port 2 on slot 3. The policy action (SetBits) specifies that the bits are reset to 7 when the
traffic egresses the switch. A policy rule called Rule2 puts the condition and the action together.
-> qos port 3/2 trusted
-> policy condition Traffic destination port 3/2 802.1p 4
-> policy action SetBits 802.1p 7
-> policy rule Rule2 condition Traffic action SetBits
To activate the configuration, enter the qos apply command. See “Applying the Configuration” on
page 26-71 for more information.
For actions that set 802.1p bits, note that a limited set of policy conditions are supported. See “Condition
and Action Combinations” on page 26-32 for more information.
Note. 802.1p mapping can also be set for Layer 3 traffic, which typically has the 802.1p bits set to zero.
