Alcatel-Lucent OmniSwitch 6860 Series User Manual

Configuring BFD BFD Application Example
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 20-33
BFD Application Example
This section provides an example network configuration in which BFD is associated with the OSPF
protocol running on the network. In addition, a tutorial is also included that provides steps on how to
configure the example network topology using the Command Line Interface (CLI).
Example Network Overview
The diagram below represents a simple OSPF network consisting of three routers. On all three routers,
OSPF is associated with BFD for faster failure detection of any router on the network.
Example OSPF Network using the BFD Protocol
The following steps are used to configure the example BFD-enabled OSPF network as shown in the
diagram above.
Note. Configuring a BFD session explicitly with an IP interface name on individual routers is optional, and
must be used if user defined BFD session parameters need to be applied. All the steps for explicit
configuration are mentioned as optional.
VLAN 12
Interface 12.x.x.x
OSPF Area 0.0.0.1 with BFD
Router 1
Router ID 1.1.1.1
Router 2
Router ID 2.2.2.2
Router 3
Router ID 3.3.3.3
VLAN 23
Interface 23.x.x.x
VLAN 31
Interface 31.x.x.x

Alcatel-Lucent OmniSwitch 6860 Series Specifications

General

Model	OmniSwitch 6860 Series
Category	Switch
Maximum Ports	48
Switching Capacity	Up to 176 Gbps
Operating System	AOS (Alcatel-Lucent Operating System)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
Port Types	10/100/1000BASE-T, SFP+, QSFP+
Ports	24, 48
Power over Ethernet (PoE)	Yes
Stacking	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Form Factor	1U rack-mountable
MAC Address Table Size	32, 000
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 mm x 420 mm x 44 mm (17.3 in x 16.5 in x 1.73 in)
Power Supply	AC or DC (depending on model)
Power Consumption	Varies by model and configuration
