Configuring QoS QoS Policy Overview
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 26-31
Policy Actions
The following actions are supported and can be combined with other actions.
The CLI prevents you from configuring invalid action combinations that are never allowed; however, it
does allow you to create combinations that are supported in some scenarios. For example, an action
specifying maximum bandwidth can be combined with an action specifying priority.
Use the following “Policy Action Combinations Table” together with the “Supported Policy Actions
Table” as a guide when creating policy actions.
Supported Policy Actions Table
• ACL (disposition accept, drop, deny)
• Priority/CoS
• 802.1p ToS/DCSP Stamping and Mapping (only
applies to the outer 802.1p value; cannot modify the
inner value)
• Maximum Bandwidth
• Maximum Depth
• Tri-Color Marking (TCM) Rate Limiting
• Shared (shares the bandwidth rate between rules that
specify the same maximum bandwidth action)
• Port Redirection
• Link Aggregate Redirection
• No Cache (disables the logging of rule entries to the
• hardware cache)
• Port Disable
• Permanent Gateway IPv4/IPv6
• Mirror
Policy Action Combinations Table
Drop Priority
Stamp/
Map Max BW
Redirect
Port
Redirect
Linkagg
Port
Disable
Permanent
Gateway IP Mirror
Drop
N/ANoNoNoNoNoNoNo Yes
Priority
No N/A Yes Yes Yes Yes No Yes Yes
Stamp/Map
No Yes N/A Yes Yes Yes No Yes Yes
Max BW
No Yes Yes N/A Yes Yes No Yes Yes
Redirect
Port
No Yes Yes Yes N/A No No Yes Ye s
Redirect
Linkagg
No Yes Yes Yes No N/A No Yes Ye s
Port Disable
No No No No No No N/A No No
Permanent
Gateway IP
No Yes Yes Yes Yes Yes No N/A Yes
Mirroring
Yes Yes Yes Yes Ye s Ye s No Yes N /A
