Configuring 802.1AB Configuring 802.1AB
OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 13-10
To disable the 802.3 TLV on a switch, enter the lldp tlv dot3 command, as shown:
-> lldp chassis tlv dot3 mac-phy disable
To disable 802.3 TLV on port 5 of slot 3, enter the following command at the CLI prompt:
-> lldp port 3/5 tlv dot3 mac-phy disable
Enabling and Disabling MED TLV
The lldp tlv med command is used to control per port LLDP Media End Device (MED) TLVs
transmission in the LLDPDUs on a specific port, a slot, or all ports on a switch. When enabled, the
LLDPDU administrative status must be in the transmit state.
To enable the LLDP-MED TLV LLDPDU transmission on a switch, enter the lldp tlv med command, as
shown:
-> lldp chassis tlv med power enable
To enable the MED TLV on port 4 of slot 4, enter the following command at the CLI prompt:
-> lldp port 4/4 tlv med capability enable
To disable the MED TLV on a switch, enter the lldp tlv med command, as shown:
-> lldp chassis tlv med power disable
To disable MED TLV on port 3 of slot 4, enter the following command at the CLI prompt:
-> lldp port 4/3 tlv med capability disable
Enabling and Disabling Proprietary TLV
The OmniSwitch advertise the Access Point location information to the OmniAccess Stellar APs
connected to it through the Proprietary TLVs. The proprietary TLVs are transmitted along with the LLDP
BPDU. After LLDP is configured on the network devices, the NMS can obtain the network topology.
The WLAN management VLAN is transmitted to OmniAccess Stellar AP through LLDP using existing
Port VLAN TLV, even if the TLV is disabled by LLDP module.
The Proprietary TLV must be enabled to advertise the OmniAccess Stellar AP location. The lldp tlv
proprietary command is used to enable the Proprietary TLV.
Note. The OmniAccess Stellar AP should always be connected to the UNP Port.
To enable the Proprietary TLV transmission on a switch, enter the lldp tlv proprietary command, as
shown:
-> lldp chassis tlv proprietary enable
To enable the Proprietary TLV on port, for example port 4 of slot 4, enter the following command at the
CLI prompt:
-> lldp port 1/4/4 tlv proprietary enable
