Configuring Port Mapping Port Mapping Defaults

OmniSwitch AOS Release 8 Network Configuration Guide December 2017 page 32-2

Port Mapping Defaults

The following table shows port mapping default values.

Parameter Description CLI Command Default Value/Comments

Mapping Session

Creation

port-mapping user-port network-port No mapping sessions

Mapping Status

configuration

port-mapping Disabled

Port Mapping Direction port-mapping unidirectional

bidirectional

Bidirectional

Port Mapping Unknown

Unicast Flooding

port-mapping unknown-unicast-

flooding

Enabled
