SIP User's Manual 104 Document #: LTRT-65415
MediaPack Series
¾ To configure IP Groups:
1. Open the 'IP Group Table' page (Configuration tab > VoIP menu > Control Network
submenu > IP Group Table).
Figure 3-68: IP Group Table Page
2. Configure the IP group parameters according to the table below.
3. Click the Submit button to save your changes.
4. To save the changes to flash memory, see ''Saving Configuration'' on page 169.
Table 3-16: I
P Group Parameters
Parameter Description
Common Parameters
Description
[IPGroup_Description]
Brief string description of the IP Group.
The value range is a string of up to 29 characters. The default
is an empty field.
Proxy Set ID
[IPGroup_ProxySetId]
The Proxy Set ID (defined in ''Configuring Proxy Sets Table'' on
page 106) a
ssociated with the IP Group. All INVITE messages
destined to this IP Group are sent to the IP address associated
with the Proxy Set.
Note: Proxy Set ID 0 must not be selected; this is the device's
default Proxy.
SIP Group Name
[IPGroup_SIPGroupName]
The SIP Request-URI host name used in INVITE and
REGISTER messages sent to the IP Group, or the host name
in the From header of INVITE messages received from the IP
Group. If not specified, the value of the global parameter,
ProxyName (see ''Configuring Proxy and Registration
Parameters'' on page 115) is use
d instead.
The value range is a string of up to 49 characters. The default
is an empty field.
