Version 6.2 323 February 2011
SIP User's Manual 9. VoIP Networking Capabilities
Table 9-7: Application Type Parameters
Parameter Description
EnableDNSasOAM
Determines the application type for DNS services.
 [1] = OAMP (default)
 [0] = Control.
Note: For this parameter to take effect, a device reset is required.
EnableNTPasOAM
Determines the application type for NTP services.
 [1] = OAMP (default)
 [0] = Control.
Note: For this parameter to take effect, a device reset is required.
9.7.1.4 Multiple Interface Table Configuration Summary and Guidelines
Multiple Interface table configuration must adhere to the following rules:
îš„ Up to 16 different interfaces may be defined.
îš„ The indices used must be in the range between 0 and 15.
îš„ Each interface must have its own subnet. Defining two interfaces with addresses in
the same subnet (i.e. two interfaces with 192.168.0.1/16 and 192.168.100.1/16) is
illegal.
îš„ Subnets in different interfaces must not be overlapping in any way (i.e. defining two
interfaces with 10.0.0.1/8 and 10.50.10.1/24 is invalid). Each interface must have its
own address space.
îš„ The Prefix Length replaces the dotted decimal Subnet Mask presentation. This column
must have a value of 0-30 for IPv4 interfaces.
îš„ Only one IPv4 interface with OAMP "Application Types" must be configured. At least
one IPv4 interface with CONTROL "Application Types" must be configured. At least
one IPv4 interface with MEDIA "Application Types" must be configured. These
application types may be mixed (i.e. OAMP and CONTROL). Here are some
examples for interface configuration:
• One IPv4 interface with "Application Types" OAMP, MEDIA & CONTROL (without
VLANs).
• One IPv4 interface with "Application Types" OAMP, one other or more IPv4
interfaces with "Application Types" CONTROL, and one or more IPv4 interfaces
with "Application Types" MEDIA (with VLANs).
• One IPv4 interface with "Application Types" OAMP & MEDIA, one other or more
IPv4 interfaces with "Application Types" MEDIA & CONTROL.
• Other configurations are also possible while keeping to the above-mentioned rule.
îš„ Each network interface may be defined with a default gateway. This default gateway
address must be in the same subnet as the associated interface. Additional routing
rules may be specified in the Routing table (''Routing Table'' on page 325).
îš„ The Interface Name column may have up to 16 characters. This column allows the
user to name each interface with an easier name to associate the interface with. This
column must have a unique value to each interface and must not be left blank.
îš„ For IPv4 interfaces, the "Interface Mode" column must be set to "IPv4 Manual"
(numeric value 10).
îš„ When defining more than one interface of the same address family, VLANs must be
enabled (the VlanMode should be set to 1).
