AudioCodes MediaPack MP-124 User Manual

Version 6.2 31 February 2011
SIP User's Manual 3. Web-Based Management
3.1.4 Toolbar
The toolbar provides command buttons for quick-and-easy access to frequently required
commands, as described in the table below:
Table 3-1: Description of Toolbar Buttons
Icon Button
Name
Description
Submit
Applies parameter settings to the device (see ''Saving Configuration''
on page 169).
Not
e: This icon is grayed out when not applicable to the currently
opened page.
Burn
Saves parameter settings to flash memory (see ''Saving
Configuration'' on page 169).
Device
Actions
Opens a drop-down menu list with frequently needed commands:
 Load Configuration File: opens the 'Configuration File' page for
loading an ini file (see ''Backing Up and Loading Configuration
File'' on page 178).
 Save Configuration File: opens the 'Configuration File' page for
saving the ini file to a PC (see ''Backing Up and Loading
Configuration File'' on page 178).
 Reset: opens the 'Maintenance Actions' page for resetting the
device (see ''Resetting the Device'' on page 167).
 Software Upgrade Wizard: opens the 'Software Upgrade Wizard'
page for upgrading the device's software (see ''Software Upgrade
Wizard'' on page 175).
Home
Opens the 'Home' page (see ''Using the Home Page'' on page 53).
Help
Opens the Online Help topic of the currently opened configuration
page in the Work pane (see ''Getting Help'' on page 51).
Log off
Logs off a session with the Web interface (see ''Logging Off the Web
Interface'' on page 52).
Note: If you modify parameters that take effect only after a device reset, after you
click the Submit button, the toolbar displays the word "Reset" (in red color),
as shown in the figure below. This is a reminder to later save ('burn') your
settings to flash memory and reset the device.
Figure 3-3: "Reset" Displayed on Toolbar
