Version 6.2 429 February 2011
SIP User's Manual 10. Configuration Parameters Reference
10.12.3 Digit Collection and Dial Plan Parameters
The digit collection and dial plan parameters are described in the table below.
Table 10-38: Digit Collection and Dial Plan Parameters
Parameter Description
Web/EMS: Dial Plan Index
[DialPlanIndex]
Determines the Dial Plan index to use in the external Dial Plan
file. The Dial Plan file is loaded to the device as a *.dat file
(converted using the DConvert utility). The Dial Plan index can
be defined globally or per Tel Profile.
The valid value range is 0 to 7, where 0 denotes PLAN1, 1
denotes PLAN2, and so on. The default is -1, indicating that no
Dial Plan file is used.
Notes:
 If this parameter is configured to select a Dial Plan index, the
settings of the parameter DigitMapping are ignored.
 If this parameter is configured to select a Dial Plan index
from an external Dial Plan file, the device first attempts to
locate a matching digit pattern in the Dial Plan file, and if not
found, then attempts to locate a matching digit pattern in the
Digit Map rules configured by the DigitMapping parameter.
 This parameter can also be configured per Tel Profile, using
the TelProfile parameter.
 For a detailed description of the Dial Plan file, see ''External
Dial Plan File'' on page 230.
[Tel2IPSourceNumberMappingDi
alPlanIndex]
Defines the Dial Plan index in the external Dial Plan file for the
Tel-to-IP Source Number Mapping feature.
The valid value range is 0 to 7, defining the Dail Plan index
[Plan x] in the Dial Plan file. The default is -1 (disabled).
For a detailed description of this feature, see Modifying ISDN-to-
IP Calling Party Number.
Web: Digit Mapping Rules
EMS: Digit Map Pat terns
[DigitMapping]
Defines the digit map pattern. If the digit string (i.e., dialed
number) matches one of the patterns in the digit map, the
device stops collecting digits and establishes a call with the
collected number.
The digit map pattern can contain up to 52 options (rules), each
separated by a vertical bar (|). The maximum length of the entire
digit pattern is 152 characters. The available notations include
the following:
 [n-m]: Range of numbers (not letters).
 . (single dot): Repeat digits until next notation (e.g., T).
 x: Any single digit.
 T: Dial timeout (configured by the TimeBetweenDigits
parameter).
 S: Short timer (configured by the TimeBetweenDigits
parameter; default is two seconds) that can be used when a
specific rule is defined after a more general rule. For
example, if the digit map is 99|998, then the digit collection is
terminated after the first two 9 digits are received. Therefore,
the second rule of 998 can never be matched. But when the
digit map is 99s|998, then after dialing the first two 9 digits,
the device waits another two seconds within which the caller
