Version 6.2 127 February 2011
SIP User's Manual 3. Web-Based Management
5. To save the changes to flash memory, see ''Saving Configuration'' on page 169.
An example is sh
own below of a REGISTER message for registering endpoint "101" using
registration Per Endpoint mode. The "SipGroupName" in the Request-URI is defined in the
IP Group table (see ''Configuring IP Groups'' on page 103).
REGISTER sip:SipGroupName SIP/2.0
Via: SIP/2.0/UDP 10.33.37.78;branch=z9hG4bKac862428454
From: <sip:101@GatewayName>;tag=1c862422082
To: <sip:101@GatewayName>
Call-ID: 9907977062512000232825@10.33.37.78
CSeq: 3 REGISTER
Contact: <sip:101@10.33.37.78>;expires=3600
Expires: 3600
User-Agent: Sip-Gateway-MP-118 FXS_FXO/v.6.00A.008.002
Content-Length: 0
Table 3-20: Hunt Group Settings Parameters
Parameter Description
Hunt Group ID
[TrunkGroupSettings_TrunkGroup
Id]
The Hunt Group ID that you want to configure.
Channel Select Mode
[TrunkGroupSettings_ChannelSel
ectMode]
The method for which IP-to-Tel calls are assigned to channels
pertaining to a Hunt Group. For a detailed description of this
parameter, refer to the global parameter ChannelSelectMode.
 [0] By Dest Phone Number.
 [1] Cyclic Ascending (default)
 [2] Ascending
 [3] Cyclic Descending
 [4] Descending
 [5] Dest Number + Cyclic Ascending
 [6] By Source Phone Number
 [9] Ring to Hunt Group (applicable only to FXS interfaces)
 [10] Select Trunk by Supplementary Services Table
(applicable only to BRI interfaces)
Note: For a detailed description of these options, refer to the
"global" ChannelSelectMode parameter.
Registration Mode
[TrunkGroupSettings_Registratio
nMode]
Registration method for the Hunt Group:
 [1] Per Gateway = Single registration for the entire device
(default). This mode is applicable only if a default Proxy or
Registrar IP are configured, and Registration is enabled
(i.e., parameter IsRegisterUsed is set to 1). In this mode,
the SIP URI user part in the From, To, and Contact
headers is set to the value of the global registration
parameter GWRegistrationName or username if
GWRegistrationName is not configured.
 [0] Per Endpoint = Each channel in the Hunt Group
registers individually. The registrations are sent to the
ServingIPGroupID if defined in the table, otherwise to the
default Proxy, and if no default Proxy, then to the Registrar
IP.
 [4] Don't Register = No registrations are sent by endpoints
pertaining to the Hunt Group. For example, if the device is
