Version 6.2 203 February 2011
SIP User's Manual 5. EMS-Based Management
a. In the MG Tree, right-click the Globe icon, and then click Add Region; the
Region dialog box appears.
Figure 5-3: Adding a Region
b. In the 'Region Name' field, enter a name for the Region (e.g., a geographical
name), and then click OK; the Region is added to the MG Tree list.
4. Verify that the device is up and running (by performing a ping to its IP address).
5. Add the device to the Region, by performing the following:
a. Right-click the added Region icon, and then from the shortcut menu, choose
Add MG; the MG Information dialog box appears.
Figure 5-4: Defining the IP Address
b. Enter an arbitrary name for the device, and then in the 'IP Address' field, enter the
device's IP address
c. Ensure that 'IPSec Enabled' check box is selected, and then enter the IPSec
Preshared Key (defined in Configuring IPSec on page 200).
d. Click OK; the device is added to the Region and appears listed in the MGs List.
Note: The Pre-shared Key string defined in the EMS must be identical to the one
that you defined for the device. When IPSec is enabled, default IPSec/IKE
parameters are loaded to the device.
